Name: Industrial Cyclone Dust Collector Cement Factory Dryer Reverse Air Bag Dust Removal System
Brand: Hebei Qiaoda Environmental Protection Technology Co., Ltd.
SKU: custom
Price: 175,001.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: QiaoDa

Certification: YES

Model Number: custom

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: negotiable

Packaging Details: Consultation with customers

Delivery Time: 15 word days

Payment Terms: T/T

Supply Ability: 20 units per month

Get Best Price

Product Details

Product Description

Highlight:
                                                industrial cyclone dust collector, cement dust collector, reverse air bag dust removal system


Industrial Cyclone Dust Collector Cement Factory Dryer Reverse Air Bag Dust Removal System

Product Description

The Industrial Cyclone Dust Collector for Cement Factory Dryer is an advanced reverse air bag dust removal system designed for efficient and continuous dust filtration in cement production lines, steel smelting, power plants, and other heavy industries.

This system combines cyclone separation technology with reverse air bag filtration, achieving superior dust collection efficiency while maintaining stable airflow and long service life. The air enters the lower cylinder and rotates along the tangential direction. Under the action of centrifugal force and gravity, large dust particles are separated and settle down into the ash hopper, while finer dust is captured by the high-performance filter bags. Clean air is then discharged through the outlet pipe.

The mechanical rotary reverse blower dust collector ensures low resistance (<120 Pa), high filtration efficiency (>99%), and a dust concentration of less than 10 mg/m³. This makes it ideal for use in cement plants, chemical factories, and metal processing facilities requiring continuous, low-emission dust control.

Each model is equipped with a durable fan system (7.5-55 kW), customizable dimensions, and a vibration cleaning mechanism to ensure stable operation and easy maintenance. Customization options are available according to your industrial environment and air volume requirements.

Technical Parameters

Specification	Model Number	Filter Area (m²)	Air Volume (m³/h)	Bag Length (m)	Bag Number (PCS)	Dust Removal Efficiency	Resistance (Pa)	Dimensions (Diameter * Height) (mm)	Weight (kg)
ZC-144/5	A	850	20400-30600	3.0	144	>99%	<120	Φ3530*7145	8900
ZC-144/5	B	950	40800-45900	3.5	144	>99%	<120	Φ3530*8145	11760
ZC-144/5	C	1140	40800-56100	4.0	144	>99%	<120	Φ3530*9145	14280
ZC-144/5	D	1140	51000-61200	4.0	240	>99%	<120	Φ4380*9060	16100
ZC-144/5	A	950	57000-85500	5.0	240	>99%	<120	Φ4380*10370	18270
ZC-144/5	B	1140	71400-102000	6.0	240	>99%	<120	Φ4380*11870	20039

Tags:

Heavy-Duty Industrial Cyclone Dust Collector with Anti-Corrosion Steel Low-Noise Motor Easy Maintenance for Industrial Workshops
