Custom Low Noise Boiler Dust Collector Draft Induction Fan Variable Frequency

Product Details

Place of Origin: China

Brand Name: QiaoDa

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: Negotiable

Packaging Details: Consultation with customers

Delivery Time: 15 word days

Payment Terms: T/T

Supply Ability: 100 units per month

Get Best Price

Product Details

Product Description

Highlight:
                                                dust collector draft induction fan, low noise boiler induced draft fan, Custom  boiler induced draft fan


Custom Low Noise Boiler Dust Collector Draft Induction Fan Variable Frequency

Custom variable frequency low noise boiler dust collector induced draft fan

The centrifugal fan uses a high-speed rotating impeller to accelerate the gas, then
decelerates and changes the flow direction to convert the kinetic energy into potential
energy (pressure). In a single-stage centrifugal fan, the gas enters the impeller from
the axial direction, changes radial as the gas flows through the impeller, and then
enters the diffuser. In the diffuser, the gas changes the direction of flow and the
increase in the section area of the pipe slows down the gas flow, which converts
kinetic energy into pressure energy. * The pressure increase mainly occurs in the
impeller, followed by the diffusion process. In a multistage centrifugal fan, a reflow
is used to make the air flow into the next blade to produce a higher pressure.

Model number	Rotational speed (r/min)	Total pressure (Pa)	Flow rate (m³/b)	Internal efficiency (%)	Internal power (KW)	Shaft power (KW)	Required power (KW)
Model number	Rotational speed (r/min)	Total pressure (Pa)	Flow rate (m³/b)	Internal efficiency (%)	Internal power (KW)	Shaft power (KW)	Required power (KW)	Motor(KW)
8D	1AS0	2745	11000	75	11.2	11.4	13.1	15
		2701	13200	78	12.7	13	14.9	15
		2612	15400	81	13.8	14.1	16.2	18.5
		2479	17600	83	14.6	14.8	17	18.5
		2346	19800	82	15.7	16.I	18.5	22
		2214	22000	80	16.9	17.3	19.8
		2036	24200	77	17.8	18,I	20.9
		1859	26400	74	18.4	18.8	21.6
9D	1450	3474	15700	75	20.2	20.6	23.7	30
		3418	18800	78	22.9	23.4	26.9
		3306	21900	81	24.8	25.3	29.1
		3138	25000	83	26.3	26.8	30.8
		2969	28100	82	28.3	28.8	33.2	15
		2801	31300	80	30.4	31.】	35.7
		2577	34400	77	32	32.6	37.5
		2353	37500	74	33.1	33.8	38.9
10D	1450	4289	21500	75	34.2	34.9	40.	45
		4220	25800	78	38.8	39.6	A5.5	45
		4081	30000	81	42	42.8	49.3	55
		3874	34300	83	44.S	4S.	S2.2	55
		3666	38600	82	7.9	48.9	S6.3	75
		3459	42900	80	51.5	S2.6	605
		3182	47200	77	S4.2	55.3	63.6
		2905	51500	74	S6.2	S7.3	65.9
1ID	】450	5190	28600	75	55	56	65	75
		5106	34300	78	62	64	73	75
		4938	40000	81	68	69	79	90
		4688	45700	83	72	73	84	90
		4436	S1400	82	77	79	9】	110
		4185	57100	80	83	85	97
		3850	62800	77	87	89	102
		3515	68500	74	90	92	106

Custom Low Noise Boiler Dust Collector Draft Induction Fan Variable Frequency 0
