Product Details
Place of Origin: China
Brand Name: Qiaoda
Certification: CE
Model Number: Customized
Payment & Shipping Terms
Minimum Order Quantity: 1 pc
Price: USD 840~3000/pc
Packaging Details: wooden package
Delivery Time: 25~30 days
Payment Terms: L/C, T/T
Supply Ability: 20 pcs/month
Dust Removal: |
Pulse Jet Blowing |
Core Components: |
PLC, Fan, Filter Cartridge |
Filter Bag Size: |
325*600mm |
Application: |
Chemical Factory/metallurgy/Power Plant |
Dimension(l*w*h): |
Depend |
After-sales Service Provided: |
Online Support |
Certification: |
CE,ISO |
Efficiency: |
99.99% |
Product Name: |
Automatic Cleaning Industrial Filter Cartridge Dust Collector |
Main Function: |
Removing Industrial Dust |
Dust Removal: |
Pulse Jet Blowing |
Core Components: |
PLC, Fan, Filter Cartridge |
Filter Bag Size: |
325*600mm |
Application: |
Chemical Factory/metallurgy/Power Plant |
Dimension(l*w*h): |
Depend |
After-sales Service Provided: |
Online Support |
Certification: |
CE,ISO |
Efficiency: |
99.99% |
Product Name: |
Automatic Cleaning Industrial Filter Cartridge Dust Collector |
Main Function: |
Removing Industrial Dust |
Efficient Grinding Table Industrial Dust Collector For Power Plant
1. Instructions For Use
Before using the equipment, please familiarise the user with the correct way of using the equipment.
The maintenance and repair described in the instruction manual are for the safety of the user and the good operation of the equipment.
The company is not responsible for personal injury and property damage caused by improper use of the product.
Before using this equipment, please read this manual carefully, and place the manual in an easily accessible place for on-site use.
Operation is as follows:
(1) Push the equipment to the work site, the ground level, confirm the connection of the relevant accessories. Step down the fixed casters of the equipment to prevent the equipment from sliding.
(2) After connecting the power supply, open the main power supply of the equipment, and then press the motor run switch, the equipment start indicator light. (If you find a murmur, be sure to turn off the motor, and then turn off the power supply of the equipment, check and adjust the equipment screws are loose, open the box operation should be operated step by step, prohibit the destruction of the internal structure of the equipment)
(3) 72 hours after the normal use of the equipment, in order to ensure the subsequent use of the effect and the service life of the filter cartridge is recommended to clean up the dust attached to the filter cartridge in a timely manner.
(4) After using the equipment for a period of time, you need to clean up the dust in the dust hopper, use the triangle key to open the filter room to clean up the dust hopper.
(5) Equipment with a longer time, the parts of the cleanup also need to pay attention to the parts of the upper air intake warehouse cleanup work, check the dust situation, timely cleaning.
(6) On the left side of the box has a power inlet, ordinary air pressure tube into the automatic locking, pull out by holding the edge of the pull out can be.
2. Parameter Description
Take QD-DM2000 model for example:
Air Volume | 3000m3/h | Power | 3kw |
Power | 380V, 50HZ(optional) | Filter Cartridge | Φ325*500mm, 3 pcs |
External Size | 2000*1000*800mm | Cleaning Method | Pulse Valve |
Pulse Valve | 1.0 inch, 3 pc | Noise | <85 dB |
Purification Efficiency | 99.97% |
3. Equipment Features
(1) With special dust removing fan and brand motor, it adopts anti-overload circuit to prevent the motor from burning out, with high safety and stable working performance.
(2) Pulse cleaning: Adopt omni-directional pulse blowback cleaning, make the surface of the filter cartridge clean more thoroughly and cleanly, and always ensure that the dust collector has a constant amount of suction air; the air compressor is connected with high-pressure hose, and high-pressure air inlet at the bottom, which can guarantee that the purifier is always in a good working condition. (Automatic or manual control can be designed according to users' requirements)
(3) The filter cartridge has a long service life, can absorb dust particles of 0.3μm, and has a good filtration effect on wet and sticky dust.
(4) The purifier internal adopts three protection measures for fire hazard and large particles of metal dust, which makes the purifier's service life longer, safer and more reliable.
(5) Clean air is evenly guided and dispersed from the direction of the grille-like exhaust port, thus reducing the noise to a minimum.
(6) With special universal casters with brakes, it is convenient to move and position the equipment at will.
(7) Photoelectric control of switching on and off, high efficiency and energy saving.
(8) The consumables in the purifier have stable performance and are easy to replace.
(9) The product can choose explosion-proof parts: electronic control, motor, lights, buttons.
4. FAQ
Q: Are you a trading company or a manufacturer?
A: We are a manufacturing company. We are a professional manufacturer of dust removal and conveying equipment with more than 20 years of production.
Q: Where is your factory located?
A: The factory is located in Hebei, China, 50 minutes by rail from Beijing.
Q: Do you offer OEM services?
A: Yes. Any required logo is available.
Q: What is the production capacity of your company?
A: Our factory covers an area of more than 20,000 square meters and produces 2,000 machines a year.
Q: What certificates do you have?
A:CE / ISO / SGS
